Products Description
|
SpecifiTQion of C15 diesel engine
|
|
|
Rated Power
|
|
|
Rated Power
|
433 kW/577 HP
|
|
Maximum Torque
|
2655 Nm @ 1400 rpm/1943 lb-ft @ 1400 rpm
|
|
Rated Speed
|
1800-2100 rpm
|
|
Emission Standard
|
|
|
Emission Standard
|
EPA Tier 4 Final
|
|
General information
|
|
|
Type
|
Inline 6 cylinder
|
|
Circulation
|
4-stroke
|
|
Bore
|
137 mm
|
|
Stroke
|
171 mm
|
|
Displacement
|
15.2 l
|
|
Compression Ratio
|
17.0:1
|
|
Aspiration
|
TA
|
|
combustion system
|
Indirect injection
|
|
cooling system
|
liquid
|
|
Dimension
|
|
|
Length
|
1438 mm
|
|
Width
|
969 mm
|
|
Height
|
1248 mm
|
|
Weight
|
1666 kg
|
| 3066 | 3116 | 3126 | 3306 | C1.1 |
| C2.2 | C2.4 | C2.6 | C3.4 | C4.2 |
| C4.4 | C6.4 | C7.1 | C7 | C9 |
| C9.3 | C10 | C11 | C12 | C13 |
| C15 | C16 | C18 | C32 |
TQ C15 industrial diesel engines are rated in the range 354-433 bkW (475-580 bhp) at 1800-2100 rpm. Industries and appliTQions powered by the C15 engine include: Agriculture, Farm Tractors, Aircraft Ground Support, Drillers/Drills, Crusher/Grinders, Combines/Harvesters, Compactors/Road Rollers, Compressors, Construction, Cranes, Rock Crusher, Dredge, Forestry, General Industrial, Hydraulic Power Units, Irrigation Equipment, Loaders/Forwarders, Material Handling, Mining, Mobile Earthmoving Equipment, Paving Equipment, Pumps, Hydraulic Shovels/Dragleys , surface transport equipment and trenchers.
